ADM2483BRWZ-REEL

Product Catalog Digital Isolators
application -
Isolation Technology Magnetic Isolation
Number of channels 3
Number of Forward Channels 2
Number of reverse channels 1
Whether with voltage isolation With voltage isolation
Isolation voltage (Viso) 2500Vrms
Data rate 500Kbps
Supply voltage (Vdd) 5V; 3V
Working temperature -40℃~+85℃
See similar products Technology: Magnetic Coupling
Type: RS422, RS485
Isolated power supply: no
Number of channels: 3
Input - input side 1/input side 2: 2/1
Channel type: bidirectional
Voltage - Isolation: 2500Vrms
Common mode transient immunity (min): 25kV/μs
Data rate: 500kbps
Rise/Fall Time (Typical): 600ns, 600ns (Max)
Voltage - Power: 3 V, 5 V
Working temperature: -40°C ~ 85°C
Package/Case: 16-SOIC (0.295", 7.50mm wide)
Vendor Device Package: 16-SOIC
